Galassia
Pavimentazione autobloccante in calcestruzzo
Galassia is the perfect concrete block paving for outdoor spaces, ideal for any architectural project. Favaro1 introduces this innovative block in four dimensional variations, ensuring easy and practical installation. Comparable in aesthetics to the renowned Emotion products by Favaro1, Galassia stands out for its surface treatment and modular dimensions, perfect for simple installation and heavy-duty traffic resistance.
With a special focus on color and contrasts, Galassia offers a delicate visual balance, enhancing each element within its context. Its versatility extends to all domestic environments as well as public and commercial spaces.
Galassia is available in a range of colors that adapt to any environment: Terra d'Umbria, Giallo Ambrato, Grigio Carnico, Giallo/Grigio, and Bianco.
The block dimensions are:
- 74 x 222 mm
- 148 x 222 mm
- 222 x 222 mm
- 222 x 292 mm
Thickness varies depending on the color:
- Giallo Ambrato, Grigio Carnico, and Terra D'Umbria are available in 60 mm, 75 mm, and 100 mm thicknesses;
- Bianco is available in 75 mm thickness;
- Giallo/Grigio is available in 60 mm thickness.
Galassia adapts to any context thanks to its easy installation and resistance to heavy traffic, ensuring quick and efficient installation.
The various color options of Galassia are designed to make your home unique.
Design and quality outdoor flooring. Discover all Favaro1 floorings and find the perfect solution for your needs.
- 74 x 222 mm
- 148 x 222 mm
- 222 x 222 mm
- 296 x 222 mm
- Biotanium
- Quartz
Technical specifications
Dimensions and Packaging
- Mq/pallet: 11,17 mq
- Kg/pallet: 1480 kg
- Kg/mq: 132,5 Kg
Sp. 75 mm:
- Mq/pallet: 8,94 mq
- Kg/pallet: 1480 kg
- Kg/mq: 165,55 Kg
Sp. 100 mm:
- Mq/pallet: 6,70 mq
- Kg/pallet: 1474 kg
- Kg/mq: 220 Kg
Driveability
Access roads to residential developments with 10 to 300 units. Pedestrian urban roads with access for service vehicles with limited load and for deliveries.
Thickness 75 mm: Class 3A
Urban roads or similar subject to a maximum traffic of 500 vehicles per day and per lane, excluding heavy traffic except occasional.
Thickness 100 mm: Class --
Certifications
- CAM
- Solar Reflectance Index SRI ASTM E1980
- CE
- Slip resistance classification DIN 51130
- Slip resistance classification DIN 51097
- Freeze/thaw resistance
- Non-slip pavement DM 14/06/1989 no. 236 par. 8.2.2
- Recycled materials content DM 23/06/22
Specification item
Pavement made with vibrated concrete interlocking blocks model GALASSIA by FAVARO1, with a wearing layer having a minimum thickness of 4 mm. Physical-mechanical characteristics according to UNI EN 1338 standard: nominal dimensions 74x222/148x222/222x222/296x222 mm, nominal thickness 75 mm, tolerance on nominal thickness ±3 mm, characteristic resistance to indirect tensile splitting ≥3.6 MPa, minimum breaking load for splitting ≥250 N/mm, satisfactory slip resistance. Compliant with anti-slip requirements of DM 14/06/1989 n.236 for outdoor pavements. Environmental sustainability characteristics: absence of asbestos, recycled material content according to CAM EDILIZIA (Decree of 23-06-2022) ≥10.8%, solar reflectance index SRI (for gray material and white-based colors) according to ASTM E1980 ≥29. Installed according to the procedures indicated by UNI 11241 on subgrade prepared according to the type of expected traffic and the condition of the natural soil based on the indications of the "Catalogo per il dimensionamento delle pavimentazioni in ambito urbano" published by Assobeton, 2005.
Thickness 75 mm
Pavement made with vibrated concrete interlocking blocks model GALASSIA by FAVARO1, with a wearing layer having a minimum thickness of 4 mm. Physical-mechanical characteristics according to UNI EN 1338 standard: nominal dimensions 74x222/148x222/222x222/296x222 mm, nominal thickness 75 mm, tolerance on nominal thickness ±3 mm, characteristic resistance to indirect tensile splitting ≥3.6 MPa, minimum breaking load for splitting ≥250 N/mm, satisfactory slip resistance. Compliant with anti-slip requirements of DM 14/06/1989 n.236 for outdoor pavements. Environmental sustainability characteristics: absence of asbestos, recycled material content according to CAM EDILIZIA (Decree of 23-06-2022) ≥10.8%, solar reflectance index SRI (for gray material and white-based colors) according to ASTM E1980 ≥29. Installed according to the procedures indicated by UNI 11241 on subgrade prepared according to the type of expected traffic and the condition of the natural soil based on the indications of the "Catalogo per il dimensionamento delle pavimentazioni in ambito urbano" published by Assobeton, 2005.
Thickness 100 mm
...
Extraordinary cleaning and maintenance
The Quartz Color System is a production system based on the combination of a special mixture with a distinctive production process. The mixture involves the addition of a certain quantity of quartz to enhance the physical and chemical performance of the product, while simultaneously amplifying its technical capabilities. On the other hand, the special production process creates a specific impermeability between the treated element and the exterior, enabling easy cleaning of the flooring and reducing stains compared to an untreated Quarz Color System product. The colors remain more durable over time, enhancing the design of the flooring.
